Lindsay Broadband delivers powering solutions to ensure your CATV and broadband networks stay up and running to keep your customers happy. Lindsay’s 900 and 1350 series of standby power supplies will keep you and your customers connected.
Features
Documentation & Tools
Related Products
Solutions
Features
- Industry-proven, backup power solutions for all outdoor CATV powering applications
- 120 VAC, 220/240 VAC or user-selectable 120/220/240 VAC inputs available on all models
- Available in 900 or 1350 VA output power capacities
- Microprocessor controlled regulated, clean, quasi-square wave output
- Line-interactive ferroresonant technology provides seamless transition to standby power when the programmable line verification system detects unacceptable power conditions. Transfer back to line operation after a programmable time delay ensure line voltage & frequency stabilization to prevent false-restores & transfer cycling. Output phase is synchronized with line frequency for seamless handover of the load
- 3.2″ (8.1 cm) color touch-screen display provides an intuitive user interface for configuration set-up & operating status monitoring
- Monitored Parameters: Real-time AC line power status, battery string (charge or discharge) individual voltages & currents, output load parameters, operational mode, performance & alarm status, logs such as standby run-time dates & times, & battery installation date
- Intelligent battery management system with temperature compensation extends battery service life
- Efficient inverter design (> 85%) extends standby mode run-time
- > 90% efficiency in line mode
- Easily accessible front panel connections
- Dual output connectors (Anderson Powerpole® + 5/8”-24 coaxial)
- Hot-swappable inverter modules
- Field-selectable 63 or 89 VAC output voltages
- Line, battery & alarm LEDs display operation status at a glance
- 9 major alarm & 3 minor alarm notifications
- Optional DOCSIS® / EuroDOCSIS™ embedded status monitoring, compatible with popular network management software, allows remote monitoring via SNMP traps or Telnet access to the on board, intuitive GUI
- Excellent input & programmable output over circuit protection
- IEC 62368-1 certified, CE compliant
Documentation & Tools
Data Sheet: LBUPS 900 & 1350 Series Quasi-Square Wave Network Standby Power Supplies pdf
