Optical Solutions

FWDM Device (LWD / LBWD)

Lindsay Broadband offers a wide selection of FWDM devices for your specific applications.

Lindsay’s LWD series of WDM devices have a wide operating wavelength of 1260-1620 nm. They feature low insertion loss, high isolation, low PDL, with high reliability and stability.

Lindsay’s LBWD GPON/RFoG WDM filter module is based on thin film technology, and is designed to allow GPON wavelengths (1310 nm/1490 nm), and RFoG wavelengths (1550 nm/1610 nm) to coexist on a single fiber. This filter features low loss, excellent port-to-port isolation and unparalleled reliability. It is available in two package options: an ABS package with fiber pigtails and an LGX module with SC/APC connectors.

Lindsay’s LBWD GPON/XGS-PON/RFoG WDM filter module is based on thin film technology and is designed to allow GPON wavelengths (1310 nm/1490 nm), XGS-PON wavelengths (1270 nm/1577 nm), and RFoG wavelengths (1550 nm/1610 nm) to coexist on a single fiber. This filter features low loss, excellent port-to-port isolation and unparalleled reliability. It is available in two package options: a loose tube mini module package with fiber pigtails and an LGX module with SC/APC connectors.

Lindsay’s LBWD GPON/XGS-PON Combo filter module is based on thin film technology and is designed to allow GPON wavelengths (1310 nm/1490 nm) and XGS-PON wavelengths (1270 nm/1577 nm) to coexist on a single fiber. This WDM module allows combo-PON functionality. This filter features low loss, excellent port-to-port isolation and unparalleled reliability. It is packaged in an LGX module with SC/APC connectors.

Lindsay’s XGS-PON/1310 nm CATV or RFoG WDM filter module is based on thin film technology and is designed to allow XGS-PON wavelengths (1270 nm/1577 nm), and legacy 1310 nm CATV or RFoG wavelengths (1550 nm/1310 nm) to coexist on a single fiber. This XGS-PON/1310 nm CATV or RFoG WDM filter features low loss, excellent port-to-port isolation, and unparalleled reliability. It is available in two package options: a loose tube mini module package with 900 micron fiber and SC/APC connectors for outside plant or subscriber use and an 8-circuit ABS package with 2.0 mm fiber and SC/APC connectors for use in headend or distribution cabinets.
